Description
The DeWalt DWS 774 panel saw is powered by a 1,400 W input motor delivering 4,500 rpm to a 216 mm carbide-tipped blade. Its patented XPS cutline indicator and integrated LED illumination ensure clear visibility of both longitudinal and crosscut lines. The high-quality die-cast aluminum base and fence maintain stable, repeatable cuts, and the AirLock-compatible dust extraction port keeps the workspace clear. Bevel angles from 0° to 50° are set via positive stops for precise angled cuts.
Key Features
- 1,400 W motor input
- 216 mm blade diameter
- 4,500 rpm no-load speed
- XPS cutline indicator
- AirLock dust extraction
- 0°–50° bevel adjustment
Specifications
Brand: DeWalt
Model Number: DWS 774
Product Type: panel saw
Power (W): 1400
Blade Diameter Mm: 216
Arbor Diameter Mm: 30
No Load Speed Rpm: 4500
Bevel Angle Max Deg: 50
Protection Features: AirLock dust extraction
LED Indicators: XPS cutline indicator
Weight (g): 12000
Length (mm): 490
Height (mm): 590
Depth (mm): 550
€1.005,24
