Description
The GIGABYTE B650 UD AC Motherboard is engineered for AMD Ryzen 9000 Series CPUs and features a robust 6+2+2 Phases VRM design. This motherboard supports memory speeds of up to 8000MHz DDR5 (OC) and offers flexible connectivity options including 1x PCIe 5.0 and 2x PCIe 4.0 M.2 slots. It is equipped with Gigabit Ethernet LAN, Wi-Fi 5 capabilities, and multiple USB ports including USB 3.2 Gen 2. The motherboard form factor is ATX and it comes in a sleek Bronze color. With support for AMD B650 chipset, the B650 UD AC includes a comprehensive audio setup with 7.1 channels output and is compatible with AMD's Ryzen 7000, 8000, and 9000 Series processors using the Socket AM5. It also features four memory slots accommodating a total maximum internal memory of 256 GB with 64 GB maximum per slot, supports unbuffered memory, and offers dual-channel architecture.
Key Features
- 6+2+2 Phases VRM
- Supports AMD Ryzen 7000, 8000, and 9000 Series CPUs
- 8000MHz DDR5 (OC) memory support
- 1x PCIe 5.0 and 2x PCIe 4.0 M.2 slots
- Gigabit Ethernet LAN
- Wi-Fi 5 connectivity
- 7.1 channels audio output
- Supports up to 256 GB total memory
Specifications
Brand: Gigabyte
Model Number: B650UDAC-Y1
Product Type: Motherboard
Color: Bronze
Weight (g): 1330
Width (mm): 270
Height (mm): 80
Length (mm): 335
Compatible Processor Series: AMD Ryzen 7000, 8000, 9000 Series
Supported Processor Sockets: Socket AM5
Maximum Internal Memory: 256
Maximum Internal Memory Per Slot: 64
Number Of Memory Slots: 4
Memory Channels: Dual-channel
Supported Memory Types: DDR5-SDRAM
Battery Count: 1
Battery Technology: Lithium-Manganese Dioxide (LiMnO2)
Audi Chip: Realtek ALC897
Number Of Cpu Fan Connectors: 2
Number Of Rgb Led Pin Headers: 4
Front Panel Audio Connector: true
Usb 3.2 Gen 2 Ports Quantity: 2
Number Of Sata Iii Connectors: 4
Bios Type: UEFI AMI
Support Raid: true
€239,86
