Description
The Planet PWR-120-48 is a power supply unit rated at 120 watts, designed in a sleek combination of blue and grey. It features a passive cooling system and a wide AC input voltage range of 100 - 240 V, with an input current of 2.25 A and an operating frequency of 50 - 60 Hz. This power supply has dimensions of 112 mm in width, 264 mm in length, and 213 mm in height, while weighing 2300 grams. It also includes safety features such as short circuit, over voltage, overheating, and overload protection. The unit operates efficiently within a temperature range of -20 to 70 °C and has a storage temperature capability of -40 to 85 °C.
Key Features
- 120 W output power
- AC input voltage: 100 - 240 V
- Input current: 2.25 A
- Passive cooling type
- Dimensions: 112 mm x 264 mm x 213 mm
- Weight: 2300 g
- Power protection features: Short circuit, Over voltage, Overheating, Overload
Specifications
Brand: Planet
Model Number: PWR-120-48
Product Type: Power supply
Weight (g): 2300
Width (mm): 112
Length (mm): 264
Height (mm): 213
Power (W): 120
Ac Input Voltage: 100 - 240 V
Input Current: 2.25
Ac Input Frequency: 50 - 60 Hz
Operating Temperature C: -20 - 70
Storage Temperature C: -40 - 85
HS Code: 84733020
€105,03
