Description
The PLANET MGB-TLB20 is a hot-swappable SFP transceiver module for 1000Base-LX Gigabit Ethernet over single-mode fiber. Operating at a wavelength of 1550 nm, it delivers data transmission up to 20 km via an LC duplex connector and fully complies with IEEE 802.3z standards. The module features digital diagnostic monitoring (DDM) for real-time measurement of temperature, voltage, and optical power, while its low power consumption suits long-haul links. This SFP unit supports operating temperatures from 0 °C to 70 °C for reliable performance in enterprise and telecommunications networks.
Key Features
- 1000Base-LX SFP transceiver
- 1550 nm wavelength
- Single-mode fiber
- Up to 20 km range
- LC Duplex connector
- DDM support
Specifications
Brand: PLANET
Model Number: MGB-TLB20
Product Type: SFP transceiver
Data Rate Mbps: 1000
Wavelength Nm: 1550
Fiber Type: Single-mode
Max Distance Km: 20
Connector Type: LC Duplex
Standards: IEEE 802.3z
Ddm Support: true
Operating Temperature Min C: 0
Operating Temperature Max C: 70
€84,24
