Network Parameters Port Number: 12 Gigabit PoE ports, 4 Gigabit Hi-PoE ports, 2 Gigabit RJ45 ports and 2 Gigabit fiber ports Port Type: RJ45 port, full duplex, MDI/MDI-X adaptive Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z Forwarding Mode: Store-and-forward switching Ports for long-distance transmission: Ports 13 to 16 MAC Address Table: 8K Switching Performance: 40 Gbps Packet Forwarding Rate: 29.76 Mpps Internal Cache: 4.1 Mbits PoE Power Supply PoE Standard: Ports 1 to 4: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Ports 5 to 16: IEEE 802.3af, IEEE 802.3at PoE Power Pin: Ports 5 to 12: Ethernet cables 1/2/3/6 supply power. Ports 1 to 4 and 13 to 16: Ethernet cables 1/2/3/6 and 4/5/7/8 supply power simultaneously. PoE Port: Ports 1 to 16 Max. Port Power: Ports 1 and 4: 90W, Ports 5 to 16: 30W Hi-Port: Ports 1 to 4 PoE Power Budget: 225W Dial-up Long Range: Ports 13 to 16: up to 300 m and the port speed is 10 Mbps. Port Isolation: Ports 1 to 16: Port isolation mode to improve network security. PoE Watchdog: Ports 1 to 16: Automatic detection and restart of unresponsive cameras. General Weight: 2.79 kg Dimensions: 440 mm x 220.8 mm x 44 mm Operating temperature: -10 °C to 55 °C Storage temperature: 40 °C to 85 °C Power supply: 100 to 240 VAC, 50/60 Hz, Max. 4 A Current consumption at idle:
€290,30
