4-Port PoE Repeater/Switch xPoE-4-11A-HS Description The xPoE-4-11A-HS is a miniature LAN extender used to regenerate network signals and power over installation distances longer than 100m. This ATTE extender features a fuse-protected LAN input and three network outputs with selectable operating modes and selective power transmission. Using multiple amplifiers allows for scaling network structures and effectively multiplying the total operating range of end devices. Another advantage of the PoE repeater is its small size. The compact housing, made in the Heat Shrink standard, ensures proper insulation of internal components and guarantees an appropriate level of tolerance to extreme temperatures. The xPoE 4-11A HS switch is designed for use with IP cameras and other network devices powered by the 802.3at/af and PoE PASSIVE standards. Applications . The xPoE411AHS Extender is ideal for places where the installation of additional devices was not planned at the time of network design. The xPoE 4411AHS Switch regenerates the network signal and transfers power to selected ports. It is also worth noting that these devices can be installed in cascades and additional devices can be connected until the output port budget is exceeded. The compact housing allows for convenient device placement depending on the prevailing conditions. Specifications LAN ports: 4 RJ45 10/100Mbps ports (auto MDI-MDIX, auto-negotiation). Supported PoE receivers (standard / max power): . 802.3af - up to 15.4W LAN2..LAN4; 802.3at - up to 30W LAN2..LAN4; PoE PASSIVE - up to 40W LAN2..LAN4; Supported PoE transmitters (standard / max power): . LAN1; 802.3af - up to 15.4W; 802.3at - up to 30W; PoE PASSIVE - up to 40W; LAN2..LAN4; PoE PASSIVE - up to 70W; PoE outputs (standard / power mode): . LAN3.LAN4; PoE PASSIVE / mode B (4,5+) (7,8-); LAN2; PoE PASSIVE / mode A (1,2+) (3,6-) and mode B (4,5+) (7,8-); LAN1 PoE input (standard / power mode): . LAN1; 802.3at, 802.3af, PASSIVE / mode A (1,2+/-) (3,6+/-) and mode B (4,5+/-) (7,8+/-); Other PoE inputs (standard / power mode): . LAN2; PASSIVE / mode A (1,2+) (3,6-) and mode B (4,5+) (7,8-); LAN3..LAN4; PoE PASSIVE / mode B (4,5+) (7,8-); PoE input protection (overcurrent / short circuit): . LAN1; 0.75A / electronic (auto-return); Microswitch SW1 (between LAN1/LAN2 connectors): PoE standard selection (at/af) for LAN1+PoE IN (determines how xPoE will be identified by the power switch). Jumper JP1 / JP2: Power on LAN3 / power on LAN4. Input voltage range: . LAN1: Vin 35..56VDC; LAN2..LAN4: Vin 12..56VDC ; Output voltage for PoE devices: Vout Vin. Operating temperature range: -20°C..+40°C. Housing (type, material, color): HS, plastic, black. Dimensions (W/L/H): 93x42x19mm& xa0. Weight: 0.05kg. Protection class: IP20.
€65,75
