Wireless DALI gateway, bidirectional. Standby power consumption only 0.5 watts. For flush mounting. 49 x 51 mm, 20 mm deep. The connection terminals are push-in terminals for conductor cross-sections from 0.2 mm² to 2.5 mm². Up to 32 wireless universal pushbuttons, wireless directional pushbuttons, wireless central control pushbuttons, motion sensors, and white-tone and intensity double rocker switches can be programmed using the convenient tap-to-pair technology. Bidirectional wireless communication can be activated. Supply voltage 230 V at terminals N and L. The DALI bus power supply DL-N2-80mA and up to 40 DALI devices are connected to the DALI terminals. The FDG62 gateway controls DALI devices with EnOcean radio transmitters. It can only send broadcast commands. The FDG62 internally stores the dimming value and provides this value as feedback. It generates the same feedback telegrams as an FD62NPN. Therefore, actuators can be controlled using this feedback. The FDG62 fulfills the functions of a DALI master.
€130,92
