Description
The OEM TEG1105P is a desktop network switch offering five Gigabit Ethernet ports, four of which supply PoE with up to 30 W per port and a total budget of 57.8 W. It supports IEEE 802.3af/at PoE standards as well as IEEE 802.3u/802.3x link control, delivering a 10 Gbit/s switching capacity and 7.44 Mpps forwarding rate. The switch draws up to 63.7 W, accepts 51 V DC or 100–240 V AC input and measures 100 x 26 x 100 mm.
Key Features
- 5 x Gigabit Ethernet ports
- 4 PoE ports
- 57.8 W total PoE budget
- 30 W PoE per port
- 63.7 W max power consumption
- 10 Gbit/s switching capacity
Specifications
Brand: OEM
Model Number: TEG1105P
Product Type: Switch
Color: Grey
Power (W): 63.7
Input Current A: 1.25
Width (mm): 100
Height (mm): 26
Depth (mm): 100
HS Code: 85176990
LED Indicators: Power, PoE, Link, Activity
Network Standards: IEEE 802.3at, IEEE 802.3u, IEEE 802.3af, IEEE 802.3, IEEE 802.3x
Supports 10G: false
Port Type: Gigabit Ethernet (10/100/1000)
Port Count: 5
Switching Capacity Gbps: 10
Forwarding Rate Mpps: 7.44
Mac Address Table Size: 2000
Poe: true
Poe Power Per Port W: 30
Poe Budget W: 57.8
Tenda TEG1105P-4-63W-EU Network Switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
€75,84
