1-channel PoE power supply 10/100/1000Mbps 55V 90W IPM-90-550 IPM-90-550 is a single-port gigabit midspan PoE compatible with IEEE 802.3af/at/bt standards (90W) with a built-in LCD display. It is used to power devices compatible with the PoE standard in LAN networks. Placed between a switch that does not have PoE power (or does not have sufficient power budget) and network devices (e.g. cameras, access points, extenders), it allows simultaneous power supply and data transmission to IP PoE devices using a single twisted pair UTP cable with a speed of 10/100/1000 Mbps. The most important features and functions: power supply of all devices operating in various PoE standards; display showing the current operating status in a clear manner; simple PoE tester/meter function simplifies power budget calculation; specialized power supply for cascaded APT series extenders; support for PoE receivers with high power consumption; designed for work in 10/100/1000Mbps networks; high efficiency of 96%; support for Passive PoE receivers; optical signaling of operating status; port protection (against surges, overcurrent); IPM-90-550 supports all popular power standards of PoE receivers, PoE+, Hi PoE in 3 operating modes, which are selected from the manual menu. Supported PoE standards. 802.3af/at/bt standard; PoH mode equivalent to PoE+ and HiPoE for non-standard receivers; Passive PoE with auto-negotiation (e.g. all devices of the ATTE ecosystem xPoE-xx series); A unique feature of this type of solution is the built-in display. It allows you to view the current working status and support menu functions. Information available on the display. PoE standard in which the receiver was recognized and powered; number of twisted pairs over which 2P/4P power is sent; power that the receivers are currently consuming; value of the PoE power supply voltage; graphic indicator of internal temperature; graphic indicator of load level; maximum instantaneous power consumed since the time of switching on; In addition to the basic function of a universal PoE power supply, the IPM-90-550 is a convenient tool for the installer for quick start-up, power supply and diagnostics of PoE devices. It allows you to quickly measure the power consumption of receivers in order to make accurate calculations of the hold time or the capacity of the required batteries for equalization systems. Real power measurement and accurate calculations allow for disputes when designing balancing reports with long-term planning. In combination with APT and xPoE series devices, it allows us to create large-scale installations in the tree factory using only UTP cables without 230VAC power lines. This allows maximum use of the available cable and power required by receivers over long distances. The device has an IP20 protection rating, to ensure protection against weather effects and moisture condensation, it is necessary to use a suitable housing. It is also necessary to ensure sufficient space for proper air circulation and for the cable assembly, taking into account the bending radius recommended by the manufacturer. Specification: Total number of ports: 2 RJ45 ports, 1 AC IN socket; LAN 1000Mbps ports: LAN IN; LAN + PoE OUT 1000Mbps ports: LAN + PoE OUT ; PoE input standard selection: Using the button next to the display ; Supply voltage: 190.. 260 VAC, 50 Hz ; Input voltage: 55 VDC +/- 2% ; Power supply power: 90 W ; Efficiency: 96% 90W ; Surge protection: LAN+PoE OUT and AC IN ; Overload protection: LAN+PoE OUT and AC IN ; Thermal protection: LAN+PoE OUT ; Operation indication: Information displayed on the display ; PoE indication: RJ45 port LED (lt) PoE power presence ; Transmission indication: RJ45 port LED (green) - link and data transmission ; Operating temperature range: -10C.. +50C ; Dimensions (W x H x D): 67 x 126 x 42 mm ; Weight: 0.194 kg ; Protection level: IP20 ; Housing construction: Dedicated plastic housing ; Example of using IPM-90-550 to power 4 IP PoE cameras on one UTP cable using APT-5-50 switch. The operating mode used is PoE bt-90. Example of using IPM-90-550 to power 7 IP PoE cameras on one UTP cable using APT extenders. The operating mode used is PoE bt-90. .
€128,83
