Description
The DEEPCOOL PF550X-FE is an efficient ATX power supply unit offering 550 W of total power output. This black power supply features dimensions of 255 mm in width, 125 mm in length, and 200 mm in height, weighing 1600 g. Equipped with an active cooling system, it includes a single 12 cm fan located at the bottom for improved thermal performance. The efficiency rating of the unit is 85%, with an active Power Factor Correction (PFC) and a maximum output of 62.5 A for the +12V rail. The power supply incorporates several safety features, including undervoltage protection (UVP), overvoltage protection (OVP), overload protection (OPP), surge and shock protection (SIP), and short circuit protection (SCP). It operates with an input voltage range of 100 to 240 V and supports connections such as a 20+4 pin ATX motherboard power connector and 6 SATA power connectors.
Key Features
- 550 W total power
- Active PFC
- 85% efficiency
- 1 x 12 cm fan
- Active cooling type
- Overvoltage protection
- Undervoltage protection
- Overload protection
- Surge and shock protection
- Short circuit protection
Specifications
Brand: DEEPCOOL
Model Number: R-PF550X-HD0B-JGEU
Product Type: Power supply unit
Color: Black
Weight (g): 1600
Width (mm): 255
Length (mm): 125
Height (mm): 200
Power (W): 550
Voltage (V): 12
Battery Capacity (Ah): 62.5
Input Current: 8
Input Voltage: 100 - 240 V
Ac Input Frequency: 50/60 Hz
Motherboard Power Connector: 20+4 pin ATX
Sata Power Connectors: 6
Power Protection Features: UVP, OVP, OPP, SIP, SCP
€70,36
