Description
The Finder 4C.02.8.230.0060 relay module features a 230 V AC coil, two changeover contacts and a maximum switching current of 8 A with 2000 VA breaking capacity. Equipped with a green LED indicator, varistor protection, mechanical switching position display and lockable control button, it measures 64.6 mm high, 15.8 mm wide and 82.9 mm long. The module is certified to CE, UL, cRUus, IMQ, CSA, VDE and GOST standards.
Key Features
- 230 V AC coil voltage
- 8 A max switching current
- 2 changeover contacts
- Includes LED indicator and varistor
- 2000 VA max breaking capacity
- Model 4C.02.8.230.0060
Specifications
Brand: FINDER
Model Number: 4C.02.8.230.0060
Product Type: relay module
Height (mm): 64.6
Width (mm): 15.8
Length (mm): 82.9
Switching Current A: 8
Switching Capacity Va: 2000
Switching Voltage Max V: 440
Operating Voltage Min V: 184
Operating Voltage Max V: 253
Coil Resistance Ohm: 28000
Contact Material: AgNi
Connection: screw terminals
Mechanical Life Cycles: 10000000
Approvals: CE, UL, cRUus, IMQ, CSA, VDE, GOST
€62,23
