Description
The Eltako R12-200-12V is a modular switching relay designed for DIN-EN 60715 TH35 rail mounting. It features a 12 V nominal coil voltage drawing 1.9 W of control power and delivers a maximum switching current of 8 A through two normally open contacts. The compact unit measures 18 mm in width and 55 mm in height and depth, and includes a manual toggle with position indicator and 3 mm contact spacing. It withstands 2000 V between contacts and 4000 V between coil and contacts and carries an IP20/IP50 protection rating with AgSnO2 contact material.
Key Features
- 12 V nominal voltage
- 1.9 W coil power
- 8 A max switching current
- 2 NO contacts
- DIN-EN 60715 TH35 rail mounting
- 3 mm contact spacing
Specifications
Brand: ELTAKO
Model Number: R12-200-12V
Product Type: Relais de commutation
Width (mm): 18
Height (mm): 55
Depth (mm): 55
Coil Power W: 1.9
Nominal Voltage V: 12
Switching Current A: 8
Contact Material: AgSnO2
Mounting Standard: DIN-EN 60715 TH35
IP Rating: IP20/IP50
Contact Spacing Mm: 3
Voltage Withstand Contact Contact V: 2000
Voltage Withstand Coil Contact V: 4000
Operating Temperature Min C: -5
Operating Temperature Max C: 50
€64,77
