Description
The Hager ESC226 latching relay offers centralized lighting control with two normally open contacts configured for 2-pole switching. It operates on a 230 V supply and carries a rated current of 25 A per contact. Mounting on a standard 35 mm DIN rail, the modular unit simplifies panel installations and allows multiple push-button inputs to control a single circuit without continuous pressure. Its robust construction supports frequent switching cycles in both residential and commercial lighting applications.
Key Features
- 2 NO contacts
- 25 A rated current
- 230 V supply voltage
- DIN rail mount 35 mm
- Model ESC226
Specifications
Brand: Hager
Model Number: ESC226
Product Type: latching relay
Supply Voltage V: 230
Rated Current A: 25
Contact Type: NO
Poles: 2
Mounting: DIN rail 35 mm
€81,50
