ELG-100-24DA-3Y LED Transformer, LED Driver, Constant Voltage, Constant Current, 96 W, 4 A, 12 V (ELG-100-24DA-3Y)
€86,44
Description The MW MEAN WELL ELG-100-24DA-3Y is a switching LED driver offering constant voltage and constant current output up to 96 W and 4 A. It features a 12–24 V DC output range with current adjustment via a built-in DALI interface. The aluminium housing achieves IP67 protection and complies with EN61000-3-2 Class C, EN55015, EN61347-1 and EN61347-2-13 standards, including 6 kV surge immunity in accordance with IEC61000-4-5. Integrated protections cover short-circuit, overload (hiccup auto recovery) and overvoltage conditions. Key Features - 96 W output power - 4 A max output current - 12–24 V DC output range - DALI interface - IP67-rated aluminium housing Specifications Brand: MW MEAN WELL Model Number: ELG-100-24DA-3Y Product Type: LED driver Color: metal Power (W): 96 IP Rating: IP67 Width (mm): 63 Height (mm): 35.5 Depth (mm): 199 Weight (g): 850 Input Voltage Min V: 100 Input Voltage Max V: 305 Output Voltage Min V: 12 Output Voltage Max V: 24 Output Current A: 4 Protection Features: short-circuit, overload (hiccup auto recovery), overvoltage Dali Interface: true Standards: EN61000-3-2 class C, EN55015, EN61347-1, EN61347-2-13, IEC61000-4-5 surge immunity 6kV
