Description
The Finder 22.34.0.012.4340 is a 25 A modular installation contactor from the 22.34 series featuring four normally open contacts in a compact 84 × 35 × 60.8 mm housing. It uses AgSnO₂ contact material and screw terminal connections, making it suitable for resistive, lightly inductive and motor load applications. The coil can be driven with both 12 V DC and 12 V AC, delivering a maximum breaking capacity of 6250 VA and operating in temperatures from -20 °C to +50 °C. Operational status is indicated via mechanical and LED indicators, and an integrated On-Auto-Off switch provides manual control.
Key Features
- 25 A current rating
- 4 NO contacts
- AgSnO₂ contact material
- 12 V AC/DC coil voltage
- 6250 VA breaking capacity
- Screw terminal connections
Specifications
Brand: FINDER
Model Number: 22.34.0.012.4340
Product Type: installation contactor
Width (mm): 35
Height (mm): 84
Depth (mm): 60.8
IP Rating: IP20
Current Rating A: 25
Contact Configuration: 4NO
Contact Material: AgSnO₂
Breaking Capacity Va: 6250
Connection Type: screw terminal
Drop Out Time Ms: 40
Response Time Ms: 18
Coil Voltage Dc V: 12
Coil Voltage Ac V: 12
€82,22
