Description
The MW MEAN WELL ELG-200-24DA-3Y constant voltage/constant current LED driver delivers up to 201.6 W at 8.4 A with a 12–24 V DC output. It features a DALI interface for precise current control and an IP67-rated aluminum enclosure for outdoor and indoor use. Compliance with EN61000-3-2 class C, EN55015, EN61347-1, EN61347-2-13 and IEC 61000-4-5 (6 kV) ensures robust EMC performance. Integrated protections include power factor correction, overload hiccup auto-recovery, short-circuit and overvoltage defense, and it offers free-ended wire terminations on a single output channel.
Key Features
- 201.6 W max power
- 8.4 A max output current
- 12–24 V DC output voltage
- DALI dimming interface
- IP67 aluminum housing
- Power factor correction
Specifications
Brand: MW MEAN WELL
Model Number: ELG-200-24DA-3Y
Product Type: LED driver
Power (W): 201.6
Output Current A: 8.4
Output Voltage Min V: 12
Output Voltage Max V: 24
Input Voltage Min V: 100
Input Voltage Max V: 305
IP Rating: IP67
Material: Aluminum
Height (mm): 37.5
Width (mm): 71
Length (mm): 244
Weight (g): 1050
Connection: wire with free ends
Led Control: DALI
Circuit Pfc: true
Mounting On Flammable Surfaces: true
Protection Features: overload hiccup auto-recovery, short-circuit protection, overvoltage protection
Compliance: EN61000-3-2 class C, EN55015, EN61347-1, EN61347-2-13, IEC 61000-4-5 level 6 kV
Outputs Count: 1
Inputs Count: 1
€106,07
