Description
The MW MEAN WELL ELG-240-24-3Y is a constant voltage/constant current LED driver providing 240 W at up to 10 A with a 12–24 V DC output. Its IP67-rated aluminum housing meets EN61000-3-2 class C, EN55015, EN61347-1, EN61347-2-13 and IEC 61000-4-5 (6 kV) standards. Built-in protections include overload hiccup auto-recovery, short-circuit and overvoltage safeguards, and the unit is non-dimmable for fixed-output installations. Free-ended wire connections enable flexible integration into various lighting systems.
Key Features
- 240 W max output power
- 10 A max output current
- 12–24 V DC output voltage
- IP67-rated aluminum housing
- EN61347-2-13 compliant
- Non-dimmable
Specifications
Brand: MW MEAN WELL
Model Number: ELG-240-24-3Y
Product Type: LED driver
Power (W): 240
Output Current A: 10
Output Voltage Min V: 12
Output Voltage Max V: 24
IP Rating: IP67
Material: Aluminum
Height (mm): 37.5
Width (mm): 71
Length (mm): 244
Weight (g): 1050
Connection: wire with free ends
Dimmable: false
Protection Features: overload hiccup auto-recovery, short-circuit protection, overvoltage protection
Compliance: EN61000-3-2 class C, EN55015, EN61347-1, EN61347-2-13, IEC 61000-4-5 level 6 kV
Outputs Count: 1
Inputs Count: 1
€102,43
