Description
FINDER 7P.62.9.009.0485 is a Type 2+3 surge protection device for RS485, telecommunication and bus lines. Its black housing measures 91 mm high, 7 mm wide and 63.9 mm deep, fitting standard distribution cabinets. The module integrates three diodes and a radio link, handling nominal surge currents of 5 kA and 10 kA at 6 V DC nominal voltage. It operates from –40 °C to +70 °C and carries an IP20 rating.
Key Features
- Type 2+3 surge protection
- 3 diodes and 1 radio link
- 6 mm module width
- 5 kA/10 kA nominal surge current
- 6 V DC nominal voltage
- IP20 rated
Specifications
Brand: FINDER
Model Number: 7P.62.9.009.0485
Product Type: Surge protector
Color: Black
Height (mm): 91
Width (mm): 7
Depth (mm): 63.9
IP Rating: IP20
Operating Temperature C: -40...+70
Compatibility: RS485 and telecommunication lines
Nominal Leakage Current Ka: 5, 10
Nominal Voltage Dc V: 6
Spd Type: 2+3
€98,97
