Description
The Lapp ÖLFLEX H07V-K Series hook up wire (MPN 4520142) features a 2.5 mm² conductor in a single-core PVC-insulated dark blue sheath. It is supplied on a 100 m reel and supports a voltage rating of 750 V. The bare copper conductor uses a 50/30 strand configuration and the cable has an outer diameter of 3.7 mm. Flame retardant construction meets CPR certification class Eca and it operates from -30 °C to 80 °C.
Key Features
- 2.5 mm² cross-section
- Single-core PVC insulation
- 750 V voltage rating
- 100 m length
- 3.7 mm outer diameter
- Operating temperature -30 to 80 °C
Specifications
Brand: Lapp
Model Number: 4520142
Product Type: Hook Up Wire
Color: Dark Blue
Cable Shape: Single Core
Insulation Material: PVC
Length M: 100
Cross Section Mm2: 2.5
Outer Diameter Mm: 3.7
Voltage Rating V: 750
Cpr Certification: Eca
Maximum Operating Temperature C: 80
Minimum Operating Temperature C: -30
Conductor Material: Bare Copper
Fire Behaviour: Flame Retardant
Strand Spec: 50/30
€124,96
