Description
The ELTAKO AVZ12DX-UC is a monofunction timer relay offering a time range from 0.1 seconds to 40 hours for delayed switching tasks. It features screw terminal connections and copper contact material, supporting a maximum switching current of 10 A at up to 2000 W and 230 V AC. Compact dimensions of 66 mm height, 18 mm width and 58 mm depth allow easy installation in control panels. The single changeover contact configuration simplifies integration into electrical circuits requiring timed activation.
Key Features
- Time range 0.1 s–40 h
- Max switching current 10 A
- Max switching power 2000 W
- 230 V AC operating voltage
- Screw terminal connection
- Copper contact material
Specifications
Brand: ELTAKO
Model Number: AVZ12DX-UC
Height (mm): 66
Width (mm): 18
Depth (mm): 58
Power (W): 2000
Power Source: 230 V AC
Max Switching Current A: 10
Time Range Min S: 0.1
Time Range Max H: 40
Connection Type: screw terminals
Contact Material: copper
€131,90
