Description
The TELEGÄRTNER shielded RJ45 male straight connector (model J00026A2111) is designed for Cat.6A networks with data rates up to 10 Gbit/s. Its die-cast zinc housing is nickel-plated and features a snap-in locking mechanism for secure panel mounting. It accepts cables from AWG 27 to AWG 22 and includes an integrated wire manager to protect the contact plate during assembly. With dimensions of 49 mm × 13.8 mm × 16.2 mm, the connector is supplied in packs of 10 with protective caps.
Key Features
- Shielded housing
- Cat.6A compatibility
- Supports up to 10 Gbit/s
- Fits AWG 27–22 cables
- Die-cast zinc, nickel-plated body
- Pack of 10 connectors
Specifications
Brand: TELEGÄRTNER
Model Number: J00026A2111
Product Type: RJ45 connector
Network Specification: CAT 6A
Connector Gender: male
Connector Orientation: straight
Height (mm): 16.2
Width (mm): 13.8
Length (mm): 49
Material: Zinc die-cast, nickel-plated
Contact Material: Steel spring, 0.8 µm gold
Rohs Compliant: true
Pack Quantity: 10
Awg Min: 27
Awg Max: 22
Number Of Poles: 8P8C
Connector Shielding: shielded base housing
Type Of Closure: snap-in
€162,01
