Description
ABB F200 4P Differential Circuit Breaker (2CSF204101R3630) provides 4-pole AC earth leakage protection with Type A sensitivity. It is rated for 63 A nominal current and 300 mA residual current trip, with a conditional short-circuit breaking capacity of 10 kA. The device supports 230/400 V AC service voltage, withstands 4 kV impulse voltage, and dissipates 4.4 W per pole (13.2 W total) under nominal conditions. It operates across 50/60 Hz networks and mounts in modular panels.
Key Features
- 230/400 V AC service voltage
- 4-pole configuration
- 63 A rated current
- 300 mA residual current
- 10 kA short-circuit capacity
- 4.4 W power loss per pole
Specifications
Brand: ABB
Model Number: 2CSF204101R3630
Pole Count: 4
Rated Current A: 63
Residual Current Ma: 300
Conditional Short Circuit Capacity Ka: 10
Impulse Withstand Voltage Kv: 4
Frequency Hz: 50/60
Power Loss Per Pole W: 4.4
Power Loss Total W: 13.2
Product Type: Residual current circuit breaker
€196,78
