Description
The Supermicro CBL-SAST-1260-100 is a 60 cm internal storage cable that breaks out one Mini-SAS HD x8 connection to two Slimline SAS x4 ports, delivering up to eight SAS or SATA drive channels between RAID controllers or host bus adapters and compatible Supermicro server backplanes. With a characteristic impedance of 100 Ω, it supports SAS3 configurations and serves as an original replacement or system-integration component. The left-exit host-side and straight device-side connectors ensure neat routing within server chassis.
Key Features
- Mini-SAS HD x8 to 2× Slimline SAS x4 breakout
- 60 cm cable length
- 100 Ω characteristic impedance
- Supports up to eight drive channels
- Internal Supermicro server cable
Specifications
Brand: Supermicro
Model Number: CBL-SAST-1260-100
Product Type: Internal server storage cable
Cable Length (m): 0.6
Characteristic Impedance Ohm: 100
Installation Type: Internal
Host Side Connector: Mini-SAS HD x8
Host Side Connector Orientation: Left-exit
Device Side Connector: Slimline SAS x4
Device Side Connector Orientation: Straight
Device Side Connector Count: 2
Connector Configuration: 1× Mini-SAS HD x8 to 2× Slimline SAS x4
Supported Interfaces: Serial Attached SCSI, Serial ATA
Maximum Supported Drive Channels: 8
Suitable For Sas Drives: true
Suitable For Sata Drives: true
Supports Sas3: true
Suitable For Raid Controllers: true
Suitable For Host Bus Adapters: true
Suitable For Server Backplanes: true
Original Manufacturer Accessory: true
External Use: false
€78,02
