Description
The ELTAKO R91-100-8VAC is a compact switching relay designed for both flush and surface mounting in electrical installations. This single-pole normally open relay features an 8 V AC coil and handles switching currents up to 8 A. Its housing measures 50 × 26 × 32 mm and carries both IP20 and IP50 protection ratings. The relay includes manual operation with a position indicator and uses silver tin oxide contacts with a 2 mm contact spacing.
Key Features
- Coil voltage 8 V AC
- Maximum switching current 8 A
- 1 NO (T) contact configuration
- IP20 and IP50 protection rating
- Dimensions: 50 × 26 × 32 mm
Specifications
Brand: ELTAKO
Model Number: R91-100-8VAC
Product Type: Switching relay
Width (mm): 26
Height (mm): 32
Length (mm): 50
IP Rating: IP20, IP50
Coil Voltage V: 8
Switching Current A: 8
Type Of Contact: 1 NO (T)
Contact Material: AgSnO2
Contact Spacing Mm: 2
Test Voltage Contact Contact V: 2000
Test Voltage Coil Contact V: 4000
Min Temperature C: -5
Max Temperature C: 50
€71,12
