Features Width only 32mm Compliance with EN50155 and EN45545-2 railway standard DC output adjustable ( 10%) 2:1 wide input range 150% peak load capability Protections: Short circuit / Overload / Over voltage /Input reverse polarity / Input under voltage protection 4KVdc I/O isolation(Reinforced isolation) Can be installed on DIN rail TS-35/7.5 or 15 -40 +70°C wide working temperature Cooling by free air convection 3 years warranty General Specification Over current protection Normally works within 150% rated output power for more than 3 seconds and then constant current protection 105 135% rated output power with auto-recovery Over-voltage protection 12V:13.8 16.2V ; 15V:17.25 20.25V ; 24V:28.8 32.4V; Protection mode: Shut down o/p voltage re-power on to recover REVERSE POLARITY By internal MOSFET no damage recovers automatically after the fault condition removed Withstand voltage I/P-O/P:4KVDC I/P-FG:2.5KVDC O/P-FG:2.5KVDC Working temperature -40 +70°C (Refer to Derating Curve ) Safety standards IEC 62368-1 (LVD) EAC TP TC 004 approved Design refer to UL508 EMC standards With external components Compliance to EN55032 Class B;EN61000-3- 3,EN61000-4-2 3 4 5 6 8 Dimension (LxWxH)(mm) 32 x 125.2 x 102 mm.
€331,94
