Description
The TP-LINK TL-SG1016PE is an Easy Smart switch featuring 16 Gigabit RJ45 ports, including eight PoE+ ports compliant with IEEE 802.3at. It delivers a total PoE power budget of 124 W and up to 30 W per port to power devices such as Wi-Fi access points, IP cameras, or VoIP phones over a single Ethernet cable. This 1U desktop/rack-mountable switch supports Layer 2 features including QoS with four priority queues, VLANs with up to 128 IDs, IGMP snooping, link aggregation, port mirroring, cable diagnostics, and loop prevention. Centralized management is available via a web-based interface or the TP-LINK Easy Smart Configuration Utility.
Key Features
- 16 x Gigabit RJ45 ports
- 8 PoE+ ports
- IEEE 802.3at PoE+ standard
- 124 W total PoE budget (30 W per port)
- Layer 2 features: VLAN, QoS, IGMP Snooping
- 1U rack-mountable design
Specifications
Brand: TP-LINK
Model Number: TL-SG1016PE
Product Type: Easy Smart Switch
Width (mm): 294
Depth (mm): 180
Height (mm): 44
Power Source: AC 120/230 V, 50/60 Hz
Poe Standard: IEEE 802.3at
Poe Power Budget W: 124
Poe Max Power Per Port W: 30
Switching Capacity Gbps: 32
Forwarding Rate Mpps: 23.8
€180,34
